Product Description:

The automatic quick-connect coupling valve is a versatile and efficient connection system designed for industrial pneumatic networks and the tools they power. This innovative coupling valve enables tool-free, instantaneous connection and disconnection of air hoses to compressors, manifolds, and pneumatic devices like nail guns, impact wrenches, and sanders. The core mechanism employs a spring-loaded sleeve that, when pulled back, allows the insertion of a compatible "plug" or "nipple." Upon release, the sleeve snaps forward, and internal steel balls lock the plug securely in place, while simultaneously depressing a check valve to open the air flow. Disconnection is just as swift: retracting the sleeve releases the balls and allows the check valve to spring shut, automatically sealing the female half of the coupling to prevent air loss and the ingress of contaminants.

Manufactured for durability in demanding workshop and factory environments, the coupling body is typically made from hardened steel or nickel-plated brass to resist corrosion and impact. The internal check valve, a critical component for preventing air waste, is precision-engineered for a fast, leak-tight seal. These couplings are available in various industrial standards (e.g., Euro-type, Automotive) and sizes to match specific flow requirements. By eliminating the need to manually open and close a shut-off valve for every tool change, this coupling system dramatically improves workflow efficiency, reduces operator fatigue, and conserves compressed air, leading to significant energy savings in high-usage settings. It is the essential link for a modern, productive pneumatic system.

Bullet Points:

Instant Tool-Free Connection: Enables rapid and secure coupling of air hoses and tools with a simple push-and-click action.

Automatic Check Valve Seal: Cuts off air flow instantly upon disconnection, preventing energy loss and keeping the system clean.

High-Flow Coupling Valve: Designed with large internal passages to minimize pressure drop and deliver maximum power to pneumatic tools.

• Durable Industrial Construction: Made from materials like nickel-plated brass to withstand rough handling, corrosion, and high cycle counts.

Universal Standard Compatibility: Available in popular industrial formats (e.g., 1/4" NPT) to ensure interoperability with existing equipment.

Specific Application Scenario:
In an automotive repair shop, a mechanic needs to switch between an impact wrench for removing lug nuts and a blowgun for cleaning brake parts. Using these quick-connect couplings, they simply pull back the sleeve on the air hose to disconnect one tool and push to connect the next, all in a matter of seconds, without any air leaking from the hose.

Specifications:

Exhibition:

We often go to India, Mexico, Algeria for aerosol valve exhibitions. Our potable butane gas stove valves have been exported to Mexico, Ecuador, Viet Nam, India, Colombia, Russia, Ukraine, Indonesia, Peru, Philippines and other countries.

Packing and Delivery

Carton size: 560*370*220mm

Gas valve: 1500 pieces / carton

Red cover: 2500 pieces / carton

We can export the portable gas stove valves to you by LCL container and full 20ft, 40ft, 40HC container. We can use carton packing and pallet packing.
