Reliable and Sterile Bag on Valve Spray Technology for Industrial Lubricants and Food Products with Contamination-Free Delivery
Engineered for demanding applications, our industrial-grade Bag-on-Valve (BOV) aerosol system delivers unmatched reliability and purity for a diverse range of sectors. This advanced dispensing technology utilizes a robust, multi-layered polymer bag housed within a sturdy can, creating a hermetic seal that completely separates the product from the inert propellant gas.
The operating principle is simple yet brilliant. Actuation forces the propellant to compress the bag, pushing the contents through the valve without any interaction between the product and the driving gas. This results in a pure, uncontaminated, and consistent stream or spray, whether you are applying a precise amount of food-safe oil, a sterile alcohol-based disinfectant, a delicate electronic cleaner, or a high-performance lubricant.
Key Features
- Eliminates Cross-Contamination: The hermetically sealed barrier ensures the propellant never contacts the product, guaranteeing a pure and uncontaminated output every time.
- Superior Chemical Compatibility: The internal bag is engineered from advanced laminates resistant to a wide array of aggressive solvents, oils, and chemicals.
- Precise and Efficient Dispensing: Enables accurate application of expensive specialty products, reducing overspray and waste while ensuring proper coverage.
- Omni-Directional Functionality: The bag-on-valve mechanism allows for reliable spraying even upside-down, which is critical for industrial maintenance and assembly lines.
- Robust and Leak-Proof Design: Manufactured to the highest tolerances with a crimped valve seal to prevent leaks and withstand rigorous handling.
Application Example
In a food manufacturing plant, a technician needs to lubricate a conveyor belt joint in a hard-to-reach area without risking product contamination. Using a lubricant packaged in our BOV system, they can spray upside-down directly onto the joint. The food-grade lubricant is dispensed pure and clean, without any propellant mixing, ensuring compliance with strict food safety standards (e.g., NSF H1) and preventing any risk of adulteration.
Technical Specifications
| Model |
Max Capacity |
Length * Height (mm) |
Aerosol Can Size |
| JC-100-P250 |
300ml |
185 * 100 |
59 * 210 |
|
250ml |
|
53 * 210 |
| JC-100-P200 |
220ml |
145 * 100 |
53 * 180 |
|
190ml |
|
50 * 180 |
| JC-100-P150-1 |
150ml |
125 * 90 |
50 * 150/155 |
|
125ml |
|
45 * 150/155 |
| JC-100-P100 |
120ml |
100 * 90 |
50 * 125 |
|
100ml |
|
45 * 125 |
| JC-100-P80 |
80ml |
100 * 80 |
40 * 120/130 |
| JC-100-P65 |
65ml |
90 * 80 |
40 * 110/35 * 110 |
| JC-100-P50 |
50ml |
90 * 65 |
35 * 110 |
Frequently Asked Questions
Q: How does the bag-on-valve system prevent product contamination?
A: The product is sealed within a flexible, impermeable pouch. The propellant remains entirely outside this bag, acting only as a piston, so there is zero risk of it mixing with or contaminating the product.
Q: Is this BOV packaging suitable for sterile medical applications?
A: Yes. The bag can be filled and sealed in an aseptic environment, making the entire system ideal for packaging sterile products like wound spray cleaners or disinfectants where maintaining sterility is critical.
Q: Can the valve handle high-viscosity products like grease?
A: Yes, the valve and actuator can be specifically engineered to manage high-viscosity materials, providing a consistent spray or stream rather than a fine mist.
Q: Why is 360-degree operation important for an industrial spray?
A: It allows workers to apply products in confined spaces, on undersides of machinery, and at awkward angles without any loss of performance, increasing efficiency and safety.
Q: What makes your BOV system 'industrial-grade'?
A: It is built with heavier-gauge materials, more robust seals, and valves designed to withstand harsh chemicals and the demanding conditions of factory and workshop environments.
